제품 상세 정보:
|
| 제품명: | 범프/충격 테스트 기계 | 유효 탑재량: | 100kg |
|---|---|---|---|
| 웨이브 형태: | 반 사인 펄스 | 가속 범위: | 5-100 Ｇ |
| 맥박 지속 시간: | 6~18ms | 범프 반복 주파수: | 1-120 |
| 드롭 높이 범위: | 5-120mm | 최대 속도 변동: | 2.2m/s |
| 테이블 크기: | 700*800mm | ||
| 강조하다: | SKM Series bump test machine,bump test machine for electronic components,electrical products bump test machine |
||
LCD Display Bump / Impact Test Machine For Reliability Shock Testing With IEC Standard
Applicable
Specifications
| Model | SKM500 | SKM700 | SKM800 | SKM1000 |
| Table size(mm) | 500*700 | 700*800 | 800*800 | 1000*1000 |
| Payload(kg) | 50 | 100 | 200 | 500 |
| Wave form | Half sine pulse | |||
| Acceleration range(G) | 5-120 | 5-100 | 5-100 | 5-80 |
| Pluse duration(ms) | 6--18 | |||
| Bump repetition frequency | 1-120 | 1-120 | 1-120 | 1-80 |
| Drop height range | 5-120mm | 5-120mm | 5-120mm | 5-180mm |
| Max velocity variation | 2.2m/s | 2.2m/s | 2.6m/s | 2.8m/s |
| Machine dimension(mm) | 750*660*800 | 900*900*800 | 900*960*800 | 1200*1150*860 |
| Machine weight(kg) | 1000 | 1260 | 2160 | 3660 |
| Power & Air supply | AC220V ±10% 50Hz Air supply:8kg 23m3 gasholder | |||
| Standards | GB/T2423.4,GB/T2423.6, IEC68-2-29, JJG497-2000, JISC0042-1995 etc | |||
Packaging & Shipping
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case,which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless,moisture corrosion, good transparency etc
